  • TI Vandal Dome Camera
Clearance

VS-5520

TI Vandal Dome Camera
UPC # 801813162165
$199.00
Quantity discounts available
QtyPrice

B-STOCK

  • 2.0MP 1/3" Progressive Scan Panasonic CMOS Sensor
  • Min. 0.03Lux(color), 0.02Lux(B/W)
  • Max. 30fps @ 1920 x 1080
  • Auto Iris varifocal lens (f=3 ~ 9mm, F1.4) built-in


Certified B-Stock and Demo Products
All “B” stock, “DEMO” stock, EOL, Obsolete products will have limited one year warranty. Marshall Electronics is not covering any cost associated with removal of the product, reinstallation, and other associated damages

  • 2.0MP 1/3" Progressive Scan Panasonic CMOS Sensor
  • Min. 0.03Lux(color), 0.02Lux(B/W)
  • Max. 30fps @ 1920 x 1080
  • Auto Iris varifocal lens (f=3 ~ 9mm, F1.4) built-in
  • Mechanical IR cut filter for True day & night (ICR)
  • HSBLC (Highlight Suppression Backlight Compensation)
  • Superior Low Light Performance
  • Powerful Demist (anti-fog algorithm)
  • 3D Noise reduction
  • Privacy masking
  • Dual Streaming (H.264/H.264, H.264/MJPEG)
  • PoE (Power over Ethernet): 802.3af
  • Composite video output
  • 3-Axis internal camera bracket
  • SD/SDHC slot for local storage
  • Compliant with ONVIF, PSIA



VS-5521 / 5521IR Specifications
Camera Image sensor 2.0 Megapixel - 1/3" CMOS Progressive Scan Image Sensor
Synchronization Internal
Minimum Illumination 0.03 Lux (color), 0.02 Lux (B/W) with 50IRE
Eletronic shutter speed 1/30 ~ 1/67,500 sec
Image Enhancement Automatic gain control Auto, Manual
White balance mode AWB, Manual, Outdoor, Indoor
True Day & Night (TDN) Auto, Day, Night, Threshold
Backlight compensation BLC, HSBLC (Highlight Suppression Backlight Compensation)
Digital noise reduction (filter) 2DNR, 3DNR, SMART
De-Mist Supports
On-screen display English
Motion detection Supports
Privacy maskingSupports
Flip mode Horizontal, Vertical, Rotate
Lens Lens type Auto DC
Digital zoom x10 Digital Zoom
Focal length f=3 ~ 9mm, Auto Iris varifocal lens, IR Cut filter
Maximum aperture ratio F1.4
Angle of view Horizontal: 92.9(wide) ~ 31.7(tele), Vertical: 67.9(wide) ~ 23.7(tele)
IR LEDVS-5521 - Not available,
VS-5521IR - 850nm, 24Pcs
Video Video compression H.264 HP Level 4
Frame rate 30fps
Bitrate Pri: 32Kbps ~ 10Mbps, Sec: 32Kbps ~ 1Mbps
Resolutions (Max) 1920 x 1080
Video streaming Primary: H.264, Secondary: H.264, MJPEG
Color control Brightness, Contrast
Video output Composite
Backup SD card, FTP
Audio Audio compression G.711, AAC
Audio sampling rate G.711: 8KHz, AAC: 32KHz
Audio input/output 1 x line-in (3.5mm stereo), 1 x line-out (3.5mm stereo)
Integration Interface API SDK, PSIA, OnVIF
Serial connectors 1 x RS-485
Sensor input 1 x NO Contact
Alarm output 1 x NO Contact
Network Network interface Ethernet 10/100Base-T (RJ-45)
Network protocol TCP/IP, UDP, Multicast, DHCP, SMTP, HTTP, HTTPS, SNMP, RTP, RTSP, UPnP, WS-Discovery, Zero Configuration, DDNS
General Ingress protection rating IP 66
Certifications CE, FCC
Power supply DC 12V/0.8A , PoE(Power over Ethernet): 802.3af
Operating temperature -10°C ~ 50°C ( 14°F ~ 122°F )
Dimension 100Ø x 4 9.2 for Vandal Dome, 148Ø x 72.6 for Base (121.8 H)mm
3.94Ø x 1.94 for Vandal Dome, 5.83Ø x 2.86 for Base (4.8 H)in
Weight 1012g / 2.23lb
